1. Contrôle le taux de charge de batterie
2. Protège la batterie contre les surcharges et les décharges profondes

Specifications

System Voltage: 12/24V

Max. Input voltage of solar panel: 55-100V

Self-consumption: < 10mA – < 12mA

Max. Charge current: 40/50/60A

Max. Discharge current: 40/50/60A

Float voltage: 13.8V ADJ 13V…15V, *2/24V; *4/48V

Boost charging:   14.4V; *2/24V;*4/48V battery voltage less than 12V start boost charging 2 hours

Battery over voltage protection: 16.5V; *2/24V; *4/48V

Type: PWM

Working temperature: -20……..+55C

Waterproof grade: IP32

Size: 200.1mm *127mm*55.3mm

Weight: 690g
